Meridian Parking Lot Striping
Parking lot striping in Meridian, Idaho
Laid out to Meridian's stall dimensions, marked to ADA requirements, and scheduled around your hours.
Restriping, or building a new layout
The first thing we ask is your operating hours, because scheduling around them is usually more valuable to you than anything else on this page. The second is this.
Restriping repaints the layout that already exists. That is the baseline.
A new layout means establishing square reference points and building from the buildings, sidewalks, curbing or whatever fixed structures the site gives us. It takes about twice as long, which is where the price difference comes from.
When a lot has been restriped so many times that the old markings have become confusing, we may recommend sealcoating and laying out fresh instead of adding another layer of paint. That costs more than a restripe, and we say it anyway.
What Meridian requires of a parking stall
Meridian is one of the few cities in the valley that publishes its stall dimensions in detail, and they change with the parking angle. Meridian Unified Development Code, Table 11-3C-5:
| Parking angle | Stall width | Stall depth | One-way aisle | Two-way aisle |
|---|---|---|---|---|
| Parallel | 9 ft | 23 ft | 12 ft | 25 ft |
| 45 degrees | 9 ft | 19 ft | 13 ft | 25 ft |
| 60 degrees | 9 ft | 19 ft | 17 ft | 25 ft |
| 90 degrees | 9 ft | 19 ft | 25 ft | 25 ft |
Compact stalls in Meridian are shorter, not narrower.
The code allows a two foot reduction in depth, making a compact stall nine feet wide by seventeen deep. It does not allow a narrower stall. Eagle does allow eight foot compact stalls, so a layout that works in Eagle will not necessarily pass here.
The Owner's Responsibility
The code puts responsibility on the property owner to ensure the parking design, the sidewalk and the access provisions meet ADA requirements, and to ensure the size and number of accessible spaces do too (Meridian City Code 11-3C-5 and 11-3C-6).
What the ADA actually requires
Notice that an accessible car space is eight feet wide minimum and a van space is eleven, while a standard Meridian stall is nine. Accessible stalls are not standard stalls with a symbol painted in them.
| Car space width | 96 inches minimum (ADA 502.2) |
|---|---|
| Van space width | 132 inches minimum, or 96 inches where the access aisle is 96 inches (ADA 502.2) |
| Access aisle width | 60 inches minimum (ADA 502.3.1) |
| Access aisle length | The full length of the space it serves (ADA 502.3.2) |
| Shared aisle | Two spaces may share one access aisle (ADA 502.3) |
| Sign height | Bottom of the sign at least 60 inches above the ground (ADA 502.6) |
The Van Space Rule
One van space for every six, or fraction of six, required accessible spaces. Not one per six total spaces. A hundred stall lot needs four accessible spaces, one of them van accessible.
No Painted Symbol Required
The ADA requires a mounted sign and does not require a symbol painted on the pavement at all. Idaho Code 39-4116 does not allow a city to amend any accessibility provision, so the accessible parking rules in Meridian are identical to Nampa, Boise and Eagle.
How the work runs
Measure and define the positions for all parking stalls across the lot.
Snap chalk lines to ensure alignment.
Paint the accessible space symbols and markings. Compliance work drives the layout rather than getting fitted around it.
Apply Sherwin-Williams SETFAST traffic paint. Dry to the touch in 15-20 minutes.
Finish speed bumps, arrows, curbing, numbering, lettering and other stencil work.
Details & Pricing
When we find something out of compliance
Fully noncompliant stalls are uncommon. The problem we actually run into is different: the stall and the access aisle measure fine, and the sidewalk or curb ramp beside them does not comply and needs to be replaced.
When we see it, it goes in the estimate, you get told the existing condition may not comply, and if you want it corrected we quote that separately. We would rather tell you about work we were not hired for than stripe around it and let an inspector find it.
Numbered stalls & Stencils
Numbered stalls, directional arrows, speed bump markings. Wheel stop installation. Custom lettering and wording at roughly 6, 12, 24 and 36 inch sizes.
Assigned parking is one of the most common sources of resident conflict in an apartment complex, and numbering the stalls is how a property manager makes it enforceable.
Fire lane curbing
Curb color is not uniform across the valley and the International Fire Code specifies no color at all. Meridian's parking ordinance defers to the fire code official on how a fire apparatus access road gets marked.
Before we mark a fire lane here we confirm the requirement with Meridian Fire rather than painting whatever the last contractor painted.
What it costs
Striping is priced by the lineal foot and runs about $0.35 per foot in most cases.
It moves with lot size, layout complexity, stencil count, and how much curb, arrow and lettering work is involved. A restripe of a clean existing layout sits at the low end. We walk the lot, count what is there, and give you a written number before anything starts.
Lots we have striped in Meridian
Heron Village Apartments
About 73,850 square feet cleaned, crack filled, sealcoated and striped, including more than 150 numbered stalls and about 5,000 linear feet of red curbing.
View our recent projects →
Cherry Lane Apartments
About 50,000 square feet cleaned, crack filled, sealcoated, potholes patched and striped. The whole complex in two days with a three man crew. Repeat customer.
View our recent projects →Questions we get
How much does parking lot striping cost in Meridian?
About $0.35 per lineal foot in most cases. It moves with lot size, layout complexity, stencil count and how much curb and arrow work is involved. A restripe costs less than a new layout.
How long does the lot have to stay closed?
The paint is dry to the touch in about fifteen to twenty minutes. The layout takes longer than the drying, which is why we schedule around your hours and work in sections where the layout allows.
What size does Meridian require a parking stall to be?
Nine feet wide, with the depth set by the parking angle: nineteen feet at 45, 60 and 90 degrees, and twenty three feet for parallel parking. Meridian UDC Table 11-3C-5. Compact stalls can be two feet shorter but not narrower.
How many accessible parking spaces does my lot need?
It comes from ADA Table 208.2 and scales with the total. One space up to 25, two up to 50, three up to 75, four up to 100. One in every six required accessible spaces has to be van accessible.
Are accessible parking rules different in Meridian than in Nampa?
No. Idaho Code 39-4116 does not allow a city to amend any accessibility provision. Only the standard stall dimensions differ between cities, not the accessible ones.
Should we sealcoat before striping?
If the lot needs both, yes, and in that order. The sealcoat cures fully first, usually twenty four to forty eight hours depending on temperature, then the striping goes down on a clean surface.
Can you number the stalls in our apartment complex?
Yes. We did more than 150 of them at Heron Village here in Meridian. Numbering is priced per character.
Request a site walk
Our office is here in Meridian. We will come out, count what is on the lot, and tell you what it needs before anyone talks about a number.
